Comprehensive Technical Capabilities
WIN-TEC’s ELV (Extra Low Voltage) Systems division delivers turn-key design, engineering, and installation of modern smart building communications, security surveillance, and life safety technologies. We integrate surveillance, biometric access, addressable fire alarm, and high-bandwidth structured fiber cabling into unified management platforms.
Scope of Engineering Solutions
- High-Definition IP CCTV video surveillance networks with AI analytics, facial recognition, and NVR storage
- Biometric access control, RFID smart card turnstiles, and automated time-and-attendance systems
- Addressable Fire Alarm and Detection Systems (FAS) with smoke, heat, and optical flame sensors
- Emergency Voice Alarm and Public Address (PA/VA) acoustic paging systems for safe building evacuation
- Structured voice and data network cabling: Cat6 / Cat6A UTP/STP and multi-core single/multi-mode fiber optics
- Audio-visual conference room integration, video intercoms, and smart building automation (BMS) interfaces
- Central ELV control room consoles, server racks, precision PDU distribution, and uninterrupted power supply (UPS)
Engineered For Zero Downtime
Every switchboard, cable containment network, and control package engineered by WIN-TEC undergoes exhaustive multi-stage Factory Acceptance Testing (FAT) before shipment.
Technical Specifications
| Surveillance Quality | 4K / 8MP Ultra-HD IP cameras, H.265+ compression, PTZ high-speed domes |
|---|---|
| Access Architecture | Biometric fingerprint, facial recognition, RFID Mifare, multi-door TCP/IP controllers |
| Fire Standards | EN54 certified addressable panels, NFPA 72 compliance with auto-dialer alerts |
| Cabling Standards | TIA/EIA-568-C, ISO/IEC 11801 Class EA Cat6A certified up to 10 Gbps |
| Network Fiber | OM3/OM4 multimode and OS2 single-mode optical fiber backbones with fusion splicing |
| Integration Protocol | BACnet, Modbus, ONVIF Profile S/G/T compliant |
Typical Industry Applications
Request Technical Consultation
Submit your project details or technical single-line diagram (SLD). Our engineering department will respond within 24 hours.
Technical Brochure
Download comprehensive technical catalog, dimensions, rating curves, and single-line diagrams.
